Transformer turn Ratio tester

Introduction
TRT-IV is applied to measure voltage ratio of three or single phase transformer.
All the data and test results are showed on a 320*240 LCD. All the test results could
be printed by the micro printer or saved on the storage of the tester.
The tester has a good performance on auto protection and anti-disturb.

Advantage
1.Voltage ratio measurement of three or singe phase transformer
2.Group vector measurement of three phase transformer.
3.Polarity measurement of single phase transformer or CT/PT
4.Voltage ratio error calculation
5.Voltage ratio range calculation of three phase transformer
6.Current transformer ratio measurement
7.Excitation current measurement in ratio testing
8.Reproduction the AC test voltage from power source to reduce the effects of bad power source
9.Save the test results in the memory internal the tester
10.Print the test results by micro printer
11.Reverse connection detect unit to prevent the high voltage injected to the operate
12.Over current protection in test voltage
13.Upload the test results to make word report by RS232 interface

Technical parameter
1.Ratio measurement range: 1-10000
2.Group measurement: 1-12
3.Phase measurement error: 1 degree
4.Ratio measurement error: 1-2000 ± 0.2%;   2000—10000 ± 0.5%
5.Power supply: AC220V ± 10%, 50Hz
6.Size 400*350*200 mm
7.Weight 7kg
