1. Functions
1) Breakdown test of user-defined
2) Proof test
3) Calibration interface for customers
4) Unloading data to PC and making word report automatically.
5) Result print
2. Technique index
1) Rated power supply: AC 220V±10% 50/60Hz
2) Output voltage: AC 0~60KV/AC 0~80KV/AC 0~100KV
3) Rate of voltage rise: 2KV/s±10%
4) Measuring precision: 3 class
5) Times: 1-9
6) Mixing time: 0~99 second
7) Placing time: 0-9 minute 59second
8) Save 100 groups of data most
9) Voltage limit setting for proof test: 20KV----70KV
10) Hold time for proof test: 1 minute -----10 minutes
11) Environment temperatures: 5-40℃
12) Relative humidity: ≤80%RH
13) Size: 420×380×410mm3
14) Weight: 28kg
